Piping refers to the overall design and layout of a piping system, covering the entire process from material selection to installation, including:
Selection and combination of pipeline components such as pipes, fittings, valves, etc
System design: involving the matching of fluid properties, pressure, temperature and other parameters, as well as the planning of supporting structures;
Construction method: divided into open piping (exposed installation) and concealed piping (embedded in walls or underground).
The relationship between pipe fittings and piping
Subordination: Pipe fittings are an integral part of piping systems and belong to a category of “pipe components”
Specification:
Sizes:
Stainless seamless steel pipe: OD: 1/2″ – 30″;WT: Sch10s – Sch80s;Length: 1m – 12m;Production process:Â Â Hot rolling, cold rolling, cold drawing, extrusion.
Stainless welded steel pipe:OD: 1/2″ – 80″;WT: Sch5s – Sch80s;Length: 1m – 18m;
- Materials:
TP304, TP304L, TP321, TP316L, TP310S, TP904L, 2507, 2205, 2507 etc.
- Standards:
ASTM A312,A213, A268, EN 10216-2, EN10217-7, JIS G3459, JIS G3446, G3459, GOST etc.
- Application:
Water treatment; Power plant accessories; Chemical engineering; Shipbuilding; Nuclear energy; Garbage disposal; natural gas; petroleum
